A continuous coating system designed for liquid paint application, drying, curing and material handling according to the requirements of different metal products.

A liquid coating production line connects surface preparation, liquid paint application, drying or curing and workpiece handling into a coordinated production process. The equipment configuration can be adapted to different liquid coatings, workpiece geometries, production capacities and factory conditions.

ZHYAO designs and manufactures customized liquid coating production lines according to the workpiece material, dimensions, coating requirements, production output and workshop layout. The process and equipment are selected according to the actual application rather than a fixed standard configuration.

1. Liquid Coating Production Line Features

A liquid coating production line combines surface preparation, liquid paint application, drying or curing and workpiece handling into a coordinated production process. Its main advantages include:

Continuous production with reduced manual transfer between processes

More consistent liquid paint application during repeated production

Better coordination between surface preparation, spraying and drying or curing

Drying and curing conditions configured according to the selected paint

Flexible equipment and line layouts for different workpieces and workshop conditions

The final configuration depends on the paint type, workpiece characteristics, production requirements and available installation space.

2. Applicable Industries

Liquid coating production lines are widely used for metal products in automotive, machinery, construction equipment, agricultural machinery, electrical equipment, building materials, furniture and other industrial applications.

Typical applications include machine frames, vehicle components, equipment housings, metal structures, cabinets, panels and fabricated metal parts.

3. Main Components

Pretreatment System

Prepares the workpiece surface before painting by removing oil, dust, rust or other contaminants. Spray pretreatment, immersion pretreatment or other surface preparation methods can be selected according to the workpiece and coating requirements.

Drying System

Removes moisture from workpieces after wet pretreatment and prepares the surface for liquid paint application.

Liquid Painting Booth

Provides a controlled environment for liquid paint spraying. Booth configuration, ventilation and exhaust arrangements are selected according to the paint type, workpiece dimensions and spraying method.

Liquid Paint Spraying System

Applies liquid paint to the workpiece using suitable spray equipment. Manual or automatic spraying systems can be configured according to production volume, workpiece geometry and coating requirements.

Drying or Curing Oven

Provides controlled temperature and airflow conditions for drying or curing the applied coating. The configuration is selected according to the paint characteristics and required coating process.

Conveyor System

Transfers workpieces through the production stages. Conveyor type, load capacity, speed and routing are designed according to workpiece dimensions, weight and production requirements.

Exhaust and Filtration System

Removes paint mist and process air from the spraying area and provides the required exhaust and filtration conditions for the coating process.

Electrical Control System

Coordinates the operation of the conveyor, pretreatment, spraying, drying or curing equipment and other production-line components.

4. How a Liquid Coating Production Line Works

The process sequence is configured according to the liquid paint and workpiece requirements.

Loading → Surface Preparation → Drying → Liquid Paint Spraying → Flash-Off/Drying → Curing or Final Drying → Cooling & Unloading

The actual process may vary according to the paint formulation, coating specification, production capacity and required finish.

5. Project Cases

The configuration of a liquid coating production line varies according to the workpiece, paint system, production capacity and factory conditions.

Workpiece: Car muffler

Industry: Machinery Manufacturing

Coating Process: Surface Preparation → Drying → Liquid Paint Spraying → Drying/Curing

Project Scope: Customized liquid coating production line

Location: Northern Rare Earth Group Spray Painting Line Project in Jing County, China

ZHYAO develops the spraying equipment, drying or curing system, conveying arrangement and line layout according to the actual production requirements.

6. ZHYAO Customized Solution

To develop a suitable liquid coating production line, please provide the following information:

Factory Dimensions (Length, Width, Height)

Production Output (1 day = 8 hours, 1 month = 30 days)

Material of the Workpieces

Workpiece Dimensions

Workpiece Weight

Color Change Demand (Frequency)

Based on this information, ZHYAO engineers evaluate the coating process, equipment configuration and line layout, then develop a customized solution according to your production requirements and factory conditions.

7. Why Choose ZHYAO

30+ Years of Industry Experience

ZHYAO has focused on coating equipment design and manufacturing since 1995, with experience in liquid painting and other industrial coating applications.

Process-Based Design

The line is designed around the selected paint system, surface preparation requirements, spraying method and drying or curing conditions.

Customized Equipment Configuration

Painting booths, spray equipment, drying or curing ovens, conveyors, exhaust systems and controls can be configured according to the project.

Engineering & Manufacturing Support

ZHYAO provides support from process planning and equipment manufacturing to installation and commissioning.

8. Project Support & Delivery

Production Lead Time

45–90 Days

The actual production schedule depends on the line configuration, equipment quantity, customization requirements and project confirmation process.

Professional Installation

ZHYAO provides installation and commissioning support according to the project scope and site conditions.

24-Month Warranty

The equipment is covered by a 24-month warranty according to the agreed project warranty terms.

Lifetime Technical Service

After the warranty period, ZHYAO continues to provide technical support and service for the coating line.

FAQ

What types of products can be processed by a liquid coating production line?

Liquid coating lines can be configured for many metal products, including machinery components, vehicle parts, equipment housings, metal structures, cabinets and fabricated components.

What liquid paints can be used on the production line?

The equipment configuration depends on the specific paint system. Different liquid coatings may require different spraying, ventilation, drying or curing conditions, which should be considered during line design.

Can the line use automatic liquid paint spraying?

Yes. Automatic spray equipment can be configured for continuous production, while manual spraying stations can be included for workpieces or areas that require operator control.

How is the drying or curing system selected?

The drying or curing conditions depend on the paint formulation, coating thickness, workpiece material, production speed and technical requirements of the coating system.
